Wakespeed WS500 Error Codes
This is the list of WS500 error codes from the Wakespeed Communications and Configuration Guide version 2.5.2/3 June 11, 2024. It is provided solely to make it easier and quicker for WS500 users to lookup the error code.
If there is a FAULTED status, the variable errorCode will contain one of these...
- Note at this time, only one error code is retained. Multi-faults will only show the last one in the checking tree.
- Errors with + 0x8000 on them will cause the regulator to re-start, others will freeze the regulator.
- Errors with a +0x4000 will be optionally treated as a 'promiscuous' hard fault.
- If the regulator is configured in 'promiscuous Mode' these faults will be treated with an auto-restart, just like 0x8000
- Note combinations like 10, and 11 are not used. Because one cannot flash out 0's, and kind of hard to tell if 11 is a 1+1, or a real slow 2+0
- The first digit of the error code will be flashed, then a pause followed by the second digit. After a longer pause the sequence of flashes is repeated.
| Error Name | Code | Flag | Description |
|---|---|---|---|
| FC_LOOP_BAT_TEMP | 12 | 0x4000U | Battery Temperature greatly exceeded configured upper limit. |
| FC_LOOP_BAT_HIGHV | 13 | 0x4000U | Battery Voltage greatly exceeded upper limit, measured by VBat+ |
| FC_LOOP_BAT_LOWV | 14 | 0x8000U | Battery Voltage too low to operate as measured on VBat+. Damaged or missing sensing wire or fuse? (or engine not started!) |
| FC_LOOP_BAT_MAXV | 15 | 0x4000U | Voltage at Vbat+ exceeded Max Bat Volts as defined by $CPB: |
| FC_LOOP_SHORTED_BAT_TEMP | 16 | 0x4000U | Battery Temperature is shorted (Defective) |
| FC_LOOP_ALT_TEMP | 21 | 0x4000U | Alternator Temperature greatly exceeded configured upper limit. |
| FC_LOOP_ALT_TEMP_RAMP | 24 | 0x4000U | Alternator Temperature greatly exceeded configured upper limit. (2nd temp reached / exceeded while ramping - this can NOT be right, to reach target while ramping means way too risky.) |
| FC_LOOP_ALT_TEMP_ROC | 25 | Alt Temp is rising REALLY fast, damaged? | |
| INTERNAL ERROR | 31..39 | ||
| FC_SYS_FET_TEMP | 41 | Internal Field FET temperature exceed limit. | |
| FC_SYS_REQIRED_SENSOR | 42 | A 'Required' sensor is missing, and we are configured to FAULT out. | |
| FC_NO_VALT_VOLTAGE | 43 | 0x8000U | No voltage has been sensed on the VAlt+ line, blown fuse? |
| FC_EXCESSIVE_VALT_OFFSET | 44 | 0x4000U | There is excessive voltage offset between VAlt+ and VBat+ sense lines - 2.5v. (Not checked in "Split" voltage systems) |
| FC_LOOP_VALT_MAXV | 45 | 0x4000U | Voltage at VAlt+ exceeded Max Bat Volts (Plus additional allowance for IR drop) as defined by $CPB: |
| FC_LOOP_ALT_HIGHV | 46 | 0x4000U | Voltage greatly exceeded expected upper limit battery limit as measured at VAlt+ |
| FC_CAN_BATTERY_DISCONNECTED | 51 | 0x4000U | Received a generic CAN message that the battery charging bus has been disconnected. |
| FC_CAN_BATTERY_HVL_DISCONNECTED | 52 | 0x4000U | A CAN command has been received asking for the battery bus to be disconnected due to High Voltage. (Note that depending on the BMS, other alarms may trigger this same fault, ala, high charge current) |
| FC_LOG_BATTINST | 53 | Battery Instance number is out of range (needs to be from 1..100) | |
| FC_TOO_MANY_AGGERGATION | 54 | Too many different BMS's are asking to be aggregated. | |
| FC_CAN_AEBUS_FAULTED | 55 | 0x8000U | AEBus device (Discovery battery) has send a warning or fault status. As there is no fore-warning of a disconnect, treat all warnings as a pending disconnect and fault. But then do auto-restart to see if it clears. |
| FC_TOO_MANY_VEREG_DEVICE | 56 | Too many VEreg (Victron) devices present to track | |
| FC_CAN_BATTERY_LVL_DISCONNECTED | 57 | 0x4000U | A CAN command has been received asking for the battery bus to be disconnected due to Low Voltage. |
| FC_CAN_BATTERY_HC_DISCONNECTED | 58 | 0x4000U | A CAN command has been received asking for the battery bus to be disconnected due to High Current. |
| FC_CAN_BATTERY_HT_DISCONNECTED | 59 | 0x4000U | A CAN command has been received asking for the battery bus to be disconnected due to High Battery Temperature. |
| FC_CAN_BATTERY_LT_DISCONNECTED | 61 | 0x4000U | A CAN command has been received asking for the battery bus to be disconnected due to Low Battery Temperature. |
| FC_CAN_BATTERY_HVL_LIMIT | 62 | 0x8000U | A CAN status has been received that the battery has reached its upper limit, but not yet disconnecting. Charging should stop. |
| INTERNAL ERROR | 71..79 | ||
| FC_DCDC_HS_OVP | 82 | 0x4000U | Primary Battery (HS) of DC-DC converter Over-voltage trip |
| FC_DCDC_HS_UVP | 83 | 0x8000U | Primary Battery (HS) of DC-DC converter Under-voltage trip |
| FC_DCDC_LS_OVP | 84 | 0x4000U | Secondary Battery (LS) of DC-DC converter Over-voltage trip |
| FC_DCDC_LS _UVP | 85 | 0x8000U | Secondary Battery (LS) of DC-DC converter Under-voltage trip |
| FC_DCDC_OVER_TEMP | 86 | 0x8000U | DCDC Convert too hot. |
| FC_DCDC_MISCOFIG | 87 | A configuration value has exceeded the selected DC-DC converter limits. | |
| FC_DCDC_MULTICONTROLLER | 88 | More than one device seems to be trying to control the DCDC converter. | |
| FC_DCDC_MISSMATCH | 89 | Attached DCDC Converter is not same as make/model specified |
The 9x codes are special ones, they do not cause a true FAULT, but indicate some altered condition and mode of operation. Mostly these are used to support DM_RV (aka, ISO Diag) and CAN connected monitors such as the Victron Cerbo. At present these codes will only be used over ISO_DIAG (CAN), will NOT cause a Regulator hard fault, and will only be issued if the attached RBM is listed as a BMS or higher priority per RV-C (120 or above).
| Error name | Code | Flag | Description |
|---|---|---|---|
| FC_CAN_BMS_SYNC_LOST | 91 | Used to signal that an existing BMS sync has been lost and we are in an alt mode (ala, Gethome) | |
| FC_FORCED_TO_IDLE | 92 | Use to indicate that the reg has been forced into Idle via perhaps the Feature-in line, or some RPM based trigger. | |
| FC_DVCC_TIMEOUT | 93 | Device has lost the DVCC lock, reverting back to non-DVCC mode of operation. | |
| INTERNAL ERROR | 1xx | ||
| INTERNAL_DCDC_ERRORS | 21x | Note, the list of DCDC errors was removed from the document, but have been left here | |
| FC_DCDC_HS_OVP | 212 | 0x4000U | Primary Battery (HS) of DC-DC converter Over-voltage trip |
| FC_DCDC_HS_UVP | 213 | 0x8000U | Primary Battery (HS) of DC-DC converter Under-voltage trip |
| FC_DCDC_LS_OVP | 214 | 0x4000U | Secondary Battery (LS) of DC-DC converter Over-voltage trip |
| FC_DCDC_LS_UVP | 215 | 0x8000U | Secondary Battery (LS) of DC-DC converter Under-voltage trip |
| FC_DCDC_OVER_TEMP | 216 | 0x8000U | DCDC Convert too hot. |
| FC_DCDC_MISCOFIG | 217 | A configuration value has exceeded the selected DC-DC converter limit | |
| FC_DCDC_MULTICONTROLLER | 218 | More than one device seems to be trying to control the DCDC converter. |
